China SHENYANG Heavy Machinery & Mining Machinery Co. Ltd

EBZ240 Boring Machine

EBZ240 Boring Machine

Application and features
EBZ240 boring machine of economic cutting hardness ≤ 85 MPa and the maximum cutting hardness ≤ 100 MPa (in joint development of sedimentary rock layers). This kind of machine uses the component parts of sophisticated domestic and configuration design of high-quality and the complete machine is of high reliability and lower center of gravity. The machine has the reasonable roller design with sandvik760S grade carbide cutter hard rock and rock ability to adapt to semi-rock and all rock tunnel boring.

1. Hydraulic system has the function of constant power, pressure cut off and load-sensitive control and has the advantage of energy conservation and efficient. The travelling motor and reducer are of high integration with high driving force and reliable performance.

2. The transported is flat structure and can maintain stable operation with the shovel plate elevation undercover for linear motion the chain and scraper.

3. The electrical system adopts modular design and PLC control and has LCD dynamic fault display and diagnosis functions with high degree of intelligence. Wireless remote control device can be configured to achieve from the machine control.

EBZ200 Boring Machine

EBZ200 Boring Machine

Application and Features
1. A specialty manufacturer can provide reliable services for you.

2. Reliable product configuration provided guarantee for the equipment to work in poor conditions. (First class sub-vendors: Fushun Electric Motor Factory; Bearings, seals, hydraulic components are all international brands)

3. A greater cutting range can meet the requirements to open up more tunnels.

4. Indivisibility of smaller size and weight can adapt to the underground transportation requirements.

5. The significant increases in traction and more reasonable grounding area is to ensure the equipment in a variety of normal walking conditions (maximum traction capacity of 60 t)

6. More device external interface makes multifunction become possible (machine reservation: two win reproduced electric drive interface ;one hydraulic-driven interface ;one hydraulic bolt rig driver interface )

7. The application of high pressure water cooling cut down the loss of tooth (cutting head cool water pressure 8Mpa and the effective cooling sharp teeth can play a supplementary cutting role)

8. Full compliance with relevant standards promulgated by state so that the user can use the equipment without trouble.

EBZ160A Dwarf- type Boring Machine

EBZ160A Dwarf- type Boring Machine

● Application and Features
EBZ160A dwarf-type boring machine is a retractable type boring machine designed for cutting complex geological conditions tunnels. It can be applied to the minimum height of 1.8 meters tunnel and can cut half coal rock and layer of sedimentary rock festival in the whole rock section of ≤ 80 MPa.

1．Hydraulic system has the function of constant power, pressure cut off and load-sensitive control and has the advantage of energy conservation and efficient.

2．All the gears of the transmission gear box are all adopted high quality alloy material with high core hardness and suitable for low speed with heavy loads and impact resistance.

3．The travelling motor and reducer are of high integration with high driving force and reliable performance.

4．The electrical systems adopt modular design and its operation cabinet has LCD dynamic fault display and diagnosis functions with high degree of intelligence. Wireless remote control device can be configured to achieve from the machine control.

5．The complete machine has a number of patented technologies and can achieve remote control through using the wireless remote control on the Boring Machine.

EBZ160A Boring Machine

EBZ160A Boring Machine

Specification and features
EBZ160A boring machine is suitable for hardness ≤ 80Mpa coal seam; semi-coal rock tunnel boring, similar conditions are also applicable to other deposits and engineering roadway excavation.

1. Hydraulic system has the function of constant power, pressure cut off and load-sensitive control and has the advantage of energy conservation and efficient.

2. Main hydraulic parts, seals, and bearings are imported international brands that can ensure the high reliability of the complete equipment.

3. All the gears of the transmission gear box are all adopted high quality alloy material with high core hardness and suitable for low speed with heavy loads and impact resistance.

4. The electrical systems adopt modular design and its operation cabinet has LCD dynamic fault display and diagnosis functions with high degree of intelligence. Wireless remote control device can be configured to achieve from the machine control.

5. The complete machine has a number of proprietary technologies and can achieve remote control through using the wireless remote control on the boring machine.

EBZ132A Boring Machine

EBZ132A Boring Machine

Application and features
EBZ132A boring machine is suitable for hardness ≤ 70Mpa coal seam; semi-coal rock tunnel boring, similar conditions are also applicable to other deposits and engineering roadway excavation.

1. Hydraulic system has the function of constant power, pressure cut off and load-sensitive control and has the advantage of energy conservation and efficient. It adopt proportional pilot control method and easy to operate.

2. All the gears of the transmission gear box are all adopted high quality alloy material with high core hardness and suitable for low speed with heavy loads and impact resistance.

3. The travelling motor and reducer are of high integration with high driving force and reliable performance.

EBZ120 Boring Machine

EBZ120 Boring Machine

Application and Features
1. EBZ120 boring machine is suitable for hardness ≤ 60Mpa coal seam; semi-coal rock tunnel boring similar conditions are also applicable to other deposits and engineering roadway excavation. The machine has a compact and strong structure that can easily operation and apply to a small section of roadway excavation. Through the secondary conveyor it can do continuous operation with dump trucks, shuttle cars, conveyor belts and other facilities to achieve tunneling.

2. Hydraulic system has the function of constant power, pressure cut off and load-sensitive control and has the advantage of energy conservation and efficient. It adopt proportional pilot control method and easy to operate.

3. All the gears of the transmission gear box are all adopted high quality alloy material with high core hardness and suitable for low speed with heavy loads and impact resistance.

MG300(250)/710(610)

MG300(250)/710(610)

3. All the gears of the transmission gear box are all adopted high quality alloy material with high core hardness and suitable for low speed with heavy loads and impact resistance.

MG450(400)/1100(930)

MG450(400)/1100(930)

3. All the gears of the transmission gear box are all adopted high quality alloy material with high core hardness and suitable for low speed with heavy loads and impact resistance.
